包邮数控应用专业英语：面向21世纪机电类专业高职高专规划教材

1 GENERAL
1.1 TOOL MOVEMENT ALONG WORKPIECE PARTS FIGURE- INTERPOLATION
1.2 FEED FUNCTION
1.3 PART DRAWING AND TOOL MOVEMENT
1.4 CUTTING SPEED- SPINDLE SPEED FUNCTION
1.5 SELECTION OF TOOL USED FOR VARIOUS MACHINING- TOOL FUNCTION
1.6 COMMAND FOR MACHINE OPERATIONS- MISCELLANEOUS FUNCTION
1.7 PROGRAM CONFIGURATION
1.8 TOOL FIGURE AND TOOL MOTION BY PROGRAM
1.9 TOOL MOVEMENT RANGE- STROKE
2 CONTROLLED AXES
2.1 AXIS NAME
2.2 INCREMENT SYSTEM
3 PREPARATORY FUNCTION ( G FUNCTION)
4 INTERPOLATION FUNCTIONS
4.1 POSITIONING(G00)
4.2 LINEAR INTERPOLATION(GOD
4.3 CIRCULAR INTERPOLATION(G02, G03)
4.4 HELICAL INTERPOLATION(G02, G03)
4.5 HYPOTHETICAL AXIS INTERPOLATION(GOT)
4.6 THREAD CUTTING(G33)
5 FEED FUNCTIONS
5.1 GENERAL
5.2 RAPID TRAVERSE
5.3 CUTTING FEED
5.4 DWELL(G04)
6 REFERENCE POSITION
7 COORDINATE SYSTEM
7.1 MACHINE COORDINATE SYSTEM
7.2 WORKPIECE COORDINATE SYSTEM
7.3 LOCAL COORDINATE SYSTEM
7.4 PLANE SELECTION
8 COORDINATE VALUE AND DIMENSION
8.1 ABSOLUTE AND INCREMENTAL PROGRAMMING(Gg0, G91)
8.2 POLAR COORDINATE COMMAND(G15, G16)
8.3 INCH/METRIC CONVERSION(G20, G21)
8.4 DECIMAL POING PROGRAMMING
9 SPINDLE SPEED FUNCTION { S FUNCTION)
9.1 SPECIFYING THE SPINDLE SPEED WITH A CODE
9.2 SPECIFYING THE SPINDLE SPEED VALUE DIRECTLY(S5 - DIGIT COMMAND)
9.3 CONSTANT SURFACE SPEED CONTROL(G96, G97)
9.4 SPINDLE SPEED FLUCTUATION DETECTION FUNCTION(G25, G26)
10 TOOL FUNCTION {T FUNCTION)
10.1 TOOL SELECTION FUNCTION
10.2 TOOL LIFE MANAGEMENT FUNCTION
11 AUXILIARY FUNCTION
11.1 AUXILIARY FUNCTION(M FUNCTION)
11.2 MULTIPLE M COMMANDS IN A SINGLE BLOCK
11.3 M CODE GROUP CHECK FUNCTION
11.4 THE SECOND AUXILIARY FUNCTIONS(B CODES)
12 PROGRAM CONFIGULATION
12.1 PROGRAM COMPONENTS OTHER THAN PROGRAM SECTIONS
12.2 PROGRAM SECTION CONFIGURATION
12.3 SUBPROGRAM
13 FUNCTIONS TO SIMPLIFY PROGRAMMING
13.1 CANNED CYCLE
13.2 RIGID TAPPING
14 COMPENSATION FUNCTION
14.1 TOOL LENGTH OFFSET(G43, G44, G49)
14.2 AUTOMATIC TOOL LENGTH MEASUREMENT(G37)
14.3 TOOL OFFSET(G45 - G48)
14.4 CUTTER COMPENSATION B (G39 - G42)
14.5 OVERVIEW OF CUTTER COMPENSATION C (G40 - G42)
15 CUSTOM MACRO
15.1 VARIABLES
15.2 SYSTEM VARIABLES
15.3 ARITHMETIC AND LOGIC OPERATION
15.4 MACRO STATEMENTS AND NC STATEMENTS
15.5 BRANCH AND REPETITION
15.6 MACRO CALL
APPENDIX VOCABULARY
REFERENCE
